Gas Detector
Leading Manufacturers, Exporters, Wholesaler, Retailer and Retailer of Ammonia Gas Leak Detector, Chlorine Gas Leak Detector, co gas detector, Combustible Gas Detectors, Industrial Hydrogen Gas Leak Detector, LPG Gas Leak Detector, Portable Ammonia Gas Leak Detector, Portable Gas Detector, Portable Multi Gas Leak Detector and Portable Nitrogen Gas Leak Detector from Mumbai.
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Brand Name | Applied Techno systems |
| Detector Features | Adjustable Sensitivity, Battery Back-Up, Hush Feature |
| Display Type | Graphics,Graphics,Digital,Graphics,Digital,Graphics, Digital |
| Power Source | Battery |
| Principle | Electrochemical, Solid State Semiconductor Catalytic and PID. |
| Range | PPM/PPB or mg/M3. |
| Resolution | 0.1 Unit or 1 Unit (Application based) |
| Sampling Method | Diffusion |
| Display | 128 X 64 Graphics LCD |
| Alarm | Relay Contact NO+NC |
| Digital out Put | RS 232, RS 485 and Modbus Communication Protocol |
| Anolog out Put | 4-20mA |
| Accuracy | +/2% |
| Sensor Life | 2-3 Years |
Preferred Buyer From
| Location | Anywhere in India |
Features :
- Rugged construction
- Low maintenance cost
- Non corrosive body
Other Details :
- Model ATS-107M is Multi channel Ammonia gas Monitor for environmental Monitoring and Leak detection.
- The ATS-107M is an economical, yet versatile Multi channel controller with the features needed for monitoring a remote 4-20 mA gas sensor/transmitter or similar device.
- The instrument provides 24 VDC power, audio/visual alarms, alarm relays and other features.
- The ATS-107M is easy to install, designed for wall mounting and completely programmable from the front panel membrane switches.
- Accept Multi 4-20 mA Input from Remote Sensor/Transmitter.
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Measurement Range | 0-100PPM |
| Display Type | Graphics, Digital |
| Operating Time | 6 – 8 hours |
| Sensor Life | 2-3 Years |
| Data Storage | 1000 or 10000 |
| Flow Rate | 2.84 L/M |
| Response Time | <5 Second |
| Accuracy | +/2% |
| Power Source | Built in Lithium Rechargeable battery |
| Alarm | Two Levels Low High, Visual and Audible |
| Display | 128 X 64 Graphics LCD |
| Sampling Method | Diffusion, Auto Suction or Direct Plug In |
| Resolution | 0.1 Unit or 1 Unit (Application based) |
| Range | %V/V, %LEL, PPM, PPB or mg/M3 |
| Principle | Electrochemical, Solid State Semiconductor and PID (Photo Ionization) |
| Warranty | One Year |
| Weight | 0.6 KG |
| Product Code | ATS101M |
Preferred Buyer From
| Location | Anywhere in India |
Features :
- Microcontroller based embedded intelligent instruments
- 128 x 64 Graphics LCD Display
- Diffusion or Auto Suction Sampling Mode
- Long Life Rechargeable Li-Ione Battery
- Data Logger with RS 232 and USB Computer Interface
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler |
| Type | Co Detector |
| Material | ABS PLASTIC |
| Certification | ISO 9001:2015 |
| Color | Light Grey |
| Feature | Light Weight, Micro Controller Based, Waterproof |
| Power Source | Built In Lithium Rechargeable Battery |
| Warranty | 1year, One Year |
| Sound | Beep |
| Country of Origin | India |
| Brand Name | ATS 101M |
| Display Type | Digital |
| Measurement Range | 0-2000 PPM |
| Principle | Electrochemical |
| Range | PPM, PPB |
| Resolution | 0.1 Unit or 1 Unit (Application based) |
| Sampling Method | Diffusion, Auto Suction or Direct Plug In |
| Display | 128 X 64 Graphics LCD |
| Alarm | Two Levels Low High, Visual and Audible |
| Accuracy | +/2% |
| Response Time | <5 Second |
| Flow Rate | 2.84 L/M |
| Data Storage | 1000 or 10000 |
| Sensor Life | 2-3 Years |
| Operating Time | 6 – 8 hours |
| Weight | 0.6 KG |
| Dimension in mm | 115 (W) X 180 (H) X 60(D) |
| Product Code | ATS 101M |
| Payment Terms | T/T |
| Delivery Time | 1 Week |
| Packaging Details | normal packing |
Preferred Buyer From
| Location | Anywhere in India |
PORTABLE GAS MONITOR/ANALYZER MODEL ATS-101M
model ATS-101M is Portable Single/Dubel Gas Detectors are capable
of detecting Oxygen, Toxic, and Combustible gases making them
ideal for use in various environments. Compact, Light Weight
Intelligent Unit with Application Specific Sensors Sensitive to
PPB / PPM or % levels of Gases & Vapors.
The advanced Micro controller technology employed makes these ALERT METERS highly dependable,
reliable and accurate. The complete automatic operation and calibration feature leaves no
scope for user error.
These Compact, self contained and intrinsically safe designed instrument housed in a weather
proof high impact plastic case are powered with a rechargeable Lithium 3.7V Dc battery.
On switching 'ON', the instrument goes thorough its complete self integrity check, and
displays factory set Warn and Alarm values before indicating ‘Ready’ for monitoring.
While in Operation, the instrument monitors the work place continuously giving the latest
update concentration of designated Gas through diffusion sampling. Suction sampling is
possible with an optional manual or battery operated pump and adaptor. The poison resistant
Pellister or long life, integrally mounted electrochemical Sensors with inbuilt cross
interference filters are gas specific. Optionally the sensors can be mounted on an extension
cable for monitoring inaccessible locations before entry.
The instruments emits an audible beep every 15 secs that provides confidence to the user that
he is well protected. Audio, Visual also Warn and Alarms protect him from hazardous
situations.
The Warn and Alarm Values are factory set. Low Battery Alarm alerts the user to replace or
recharge the Battery. Special features like maximum exposed concentration and TWA readings
can be incorporated
Complete Automatic Operation.
128X64 Graphics Display
Continuous Diffusion / Suction Sampling
Confidence Beep every 15 seconds.
Complete self Integrity check on start
Automatic Calibration.
Display of WARN & ALARM
Low battery Alarm.
FEATURES
Sample Type: Diffussion
(Without auto suction pump)
Sample Type: Auto suction
(with inbuilt auto suction pump)
Applied Techno Engineers Pvt. Ltd.
An ISO 9001:2015 Company
Process Monitoring Instruments
FEATURES
Overall Ranges PPB / PPM / % V/V/% LEL
Sampling Method Diffusion (D) or Suction (S)
Principle Specific to Application (EC, NDIR, Solid State, Catalytic,PID)
Sensor Life 2 - 5 years
Measurement Continuous.
Display 128 X 64 graphics Display (Reading, Alarm Icon & low battery Condition)
Resolution 0.01, 0.1 or 1 PPM, %V/V, % LEL as applicable.
Accuracy +/- 2 % & 0.5% for oxygen.
Repeatability +/- 2 %.
Response Time < 30 seconds at 95 % variation.
Alarms Low & HI Visual and Audible (User Customized))
Humidity 0 - 9 5 % R H
Power Supply 3.7 V DC Long Life Lithium Rechargeable Battery
Battery Life 6-8 hours.
Housing & IP High Impact Plastic. (ABS), Ingress Protection:IP68
Size & Weight 115(H) X180(L) X 60(D); 300 GM.
Temperature Range -30 to 55 Deg. C.
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Feature | Durable, Eco Friendly |
| Usage | Gas Detecting |
| Display Type | Analog |
| Power Source | Battery |
| Warranty | 1Year |
| Gas Type | Combustible |
| Product Code | ATS |
Preferred Buyer From
| Location | Anywhere in India |
Choosing between infrared and catalytic bead technology:
Advantages of Catalytic Gas Detectors :
- Can perform more reliably in dusty/dirty atmospheres because they are not as sensitive as optics to the buildup of industrial contaminants
- Can perform more reliably in high temperature applications
- Not significantly affected by changes in pressure
- Catalytic bead sensors with a constant temperature circuit are not affected by changes in humidity. All catalytic sensors are less sensitive to Humidity and condensation
- Can detect most combustible hydrocarbons
- Can detect hydrogen which is invisible to infrared
- Smaller footprint than infrared
Calilbration Gas Selection for Combustible Gas Detectors
It is not always desirable or necessary to calibrate with the specific gas which is most likely to be present. The standard calibration gases selected by Delphian give excellent results for most applications. Delphian's calibration kit can be used to calibrate for ANY combustible gas. Delphian will recommend which calibration gas to use and provide calibration instructions
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Type | Hydrogen Gas Leak Detector |
| Application | Gas Detecting, Gas Leakage Detecting, Industrial Use |
| Color | Grey |
| Feature | Accuracy, Alarm System, Durable, Easy To Use |
| Condition | New |
| Power Source | Built In Lithium Rechargeable Battery |
| Warranty | 1Year |
| Gas Type | Hydrogen Gas |
| Country of Origin | India |
| Range 0-100% V/V | 0.1% V/V |
| Principle | Electrochemical, Solid State Semiconductor |
| Resolution | 0.1 Unit or 1 Unit (Application based). |
| Sampling Method | Diffusion, Auto Suction or Direct Plug In |
| Display | 128 X 64 Graphics LCD |
| Alarm | Two Levels Low High, Visual and Audible |
| Accuracy | +/2%. |
| Response Time | <5 Second. |
| Flow Rate | 2.84 L/M. |
| Data Storage | 1000 or 10000. |
| Sensor Life | 2-3 Years |
| Operating Time | 6 – 8 hours |
| Payment Terms | T/T |
| Delivery Time | 1 Week |
| Packaging Details | normal packing |
Preferred Buyer From
| Location | Anywhere in India |
PORTABLE GAS MONITOR/ANALYZER MODEL ATS-101M
model ATS-101M is Portable Single/Dubel Gas Detectors are capable
of detecting Oxygen, Toxic, and Combustible gases making them
ideal for use in various environments. Compact, Light Weight
Intelligent Unit with Application Specific Sensors Sensitive to
PPB / PPM or % levels of Gases & Vapors.
The advanced Micro controller technology employed makes these ALERT METERS highly dependable,
reliable and accurate. The complete automatic operation and calibration feature leaves no
scope for user error.
These Compact, self contained and intrinsically safe designed instrument housed in a weather
proof high impact plastic case are powered with a rechargeable Lithium 3.7V Dc battery.
On switching 'ON', the instrument goes thorough its complete self integrity check, and
displays factory set Warn and Alarm values before indicating ‘Ready’ for monitoring.
While in Operation, the instrument monitors the work place continuously giving the latest
update concentration of designated Gas through diffusion sampling. Suction sampling is
possible with an optional manual or battery operated pump and adaptor. The poison resistant
Pellister or long life, integrally mounted electrochemical Sensors with inbuilt cross
interference filters are gas specific. Optionally the sensors can be mounted on an extension
cable for monitoring inaccessible locations before entry.
The instruments emits an audible beep every 15 secs that provides confidence to the user that
he is well protected. Audio, Visual also Warn and Alarms protect him from hazardous
situations.
The Warn and Alarm Values are factory set. Low Battery Alarm alerts the user to replace or
recharge the Battery. Special features like maximum exposed concentration and TWA readings
can be incorporated
Complete Automatic Operation.
128X64 Graphics Display
Continuous Diffusion / Suction Sampling
Confidence Beep every 15 seconds.
Complete self Integrity check on start
Automatic Calibration.
Display of WARN & ALARM
Low battery Alarm.
FEATURES
Sample Type: Diffussion
(Without auto suction pump)
Sample Type: Auto suction
(with inbuilt auto suction pump)
Applied Techno Engineers Pvt. Ltd.
An ISO 9001:2015 Company
Process Monitoring Instruments
FEATURES
Overall Ranges PPB / PPM / % V/V/% LEL
Sampling Method Diffusion (D) or Suction (S)
Principle Specific to Application (EC, NDIR, Solid State, Catalytic,PID)
Sensor Life 2 - 5 years
Measurement Continuous.
Display 128 X 64 graphics Display (Reading, Alarm Icon & low battery Condition)
Resolution 0.01, 0.1 or 1 PPM, %V/V, % LEL as applicable.
Accuracy +/- 2 % & 0.5% for oxygen.
Repeatability +/- 2 %.
Response Time < 30 seconds at 95 % variation.
Alarms Low & HI Visual and Audible (User Customized))
Humidity 0 - 9 5 % R H
Power Supply 3.7 V DC Long Life Lithium Rechargeable Battery
Battery Life 6-8 hours.
Housing & IP High Impact Plastic. (ABS), Ingress Protection:IP68
Size & Weight 115(H) X180(L) X 60(D); 300 GM.
Temperature Range -30 to 55 Deg. C.
MOQ : 1 Piece(s)
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Type | Lpg Gas Leak Detector |
| Application | Lpg Gas Leak Detecting |
| Color | White |
| Condition | New |
| Display Type | Digital, Graphics |
| Power Source | Built In Lithium Rechargeable Battery |
| Warranty | 1Year, One Year |
| Gas Type | Combustible Gas, LPG Gas |
| Country of Origin | India |
| Brand Name | ATS 101M |
| Measurement Range | 0-100% |
| Principle | Electrochemical, Solid State Semiconductor and catalytic pellister |
| Range | %V/V, %LEL, PPM, PPB or mg/M3 |
| Resolution | 0.1 Unit or 1 Unit (Application based) |
| Sampling Method | Diffusion, Auto Suction or Direct Plug In |
| Display | 128 X 64 Graphics LCD |
| Alarm | Two Levels Low & High, Visual and Audible |
| Accuracy | /2% |
| Response Time | <5 Second |
| Flow Rate | 2.84 L/M |
| Data Storage | 1000 or 10000 |
| Sensor Life | 2-3 Years |
| Operating Time | 6 – 8 hours |
| Temperature | 15degree Celsius Humidity :< 85%RH Atmosphere Pressure: 86- 106Kpa |
| Housing | High Impact Plastic |
| Dimension in mm | 115 (W) X 180 (H) X 60(D) |
| Weight | 0.6 KG |
| Product Code | ATS101M |
| Payment Terms | T/T |
| Delivery Time | 1 Week |
| Packaging Details | Normal packing |
Preferred Buyer From
| Location | Anywhere in India |
PORTABLE GAS MONITOR/ANALYZER MODEL ATS-101M
model ATS-101M is Portable Single/Dubel Gas Detectors are capable
of detecting Oxygen, Toxic, and Combustible gases making them
ideal for use in various environments. Compact, Light Weight
Intelligent Unit with Application Specific Sensors Sensitive to
PPB / PPM or % levels of Gases & Vapors.
The advanced Micro controller technology employed makes these ALERT METERS highly dependable,
reliable and accurate. The complete automatic operation and calibration feature leaves no
scope for user error.
These Compact, self contained and intrinsically safe designed instrument housed in a weather
proof high impact plastic case are powered with a rechargeable Lithium 3.7V Dc battery.
On switching 'ON', the instrument goes thorough its complete self integrity check, and
displays factory set Warn and Alarm values before indicating ‘Ready’ for monitoring.
While in Operation, the instrument monitors the work place continuously giving the latest
update concentration of designated Gas through diffusion sampling. Suction sampling is
possible with an optional manual or battery operated pump and adaptor. The poison resistant
Pellister or long life, integrally mounted electrochemical Sensors with inbuilt cross
interference filters are gas specific. Optionally the sensors can be mounted on an extension
cable for monitoring inaccessible locations before entry.
The instruments emits an audible beep every 15 secs that provides confidence to the user that
he is well protected. Audio, Visual also Warn and Alarms protect him from hazardous
situations.
The Warn and Alarm Values are factory set. Low Battery Alarm alerts the user to replace or
recharge the Battery. Special features like maximum exposed concentration and TWA readings
can be incorporated
FEATURES
Overall Ranges PPB / PPM / % V/V/% LEL
Sampling Method Diffusion (D) or Suction (S)
Principle Specific to Application (EC, NDIR, Solid State, Catalytic,PID)
Sensor Life 2 - 5 years
Measurement Continuous.
Display 128 X 64 graphics Display (Reading, Alarm Icon & low battery Condition)
Resolution 0.01, 0.1 or 1 PPM, %V/V, % LEL as applicable.
Accuracy +/- 2 % & 0.5% for oxygen.
Repeatability +/- 2 %.
Response Time < 30 seconds at 95 % variation.
Alarms Low & HI Visual and Audible (User Customized))
Humidity 0 - 9 5 % R H
Power Supply 3.7 V DC Long Life Lithium Rechargeable Battery
Battery Life 6-8 hours.
Housing & IP High Impact Plastic. (ABS), Ingress Protection:IP68
Size & Weight 115(H) X180(L) X 60(D); 300 GM.
Temperature Range -30 to 55 Deg. C.
MOQ : 1 Piece(s)
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Brand Name | ATS |
| Gas Type | Combustible Gas |
| Operating Temp. (deg. Celsius) | -5 to 55 Deg |
| Operating Time | 6-8 Hours |
| Battery Type | Lithium Rechargeable battery |
| Humidity (%) | 95%RH |
| Resolution (PPM) | 0.1 Unit or 1 Unit |
| Response Time (s) | 5 Second |
| Sensor Type | Electrochemical |
| Electrochemical | 2-3 Years |
| Accuracy (%) | +/2% |
| Size | 115 (W) X 180 (H) X 60(D) |
| Display Type | Digital |
| Power Source | Battery |
| Product Code | ATS-101M |
Preferred Buyer From
| Location | Anywhere in India |
Key Points :
- Lcd display unit
- Robust design
- Maintenance free
- Superior performance
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Principle | Electrochemical, Solid State Semiconductor and PID (Photo Ionization) |
| Range | %V/V, %LEL, PPM, PPB or mg/M3 |
| Resolution | 0.1 Unit or 1 Unit (Application based) |
| Sampling Method | Diffusion, Auto Suction or Direct Plug In |
| Display | 128 X 64 Graphics LCD |
| Alarm | Two Levels Low & High, Visual and Audible |
| Power Source | Built in Lithium Rechargeable battery |
| Accuracy | +/2% |
| Response Time | <5 Second |
| Flow Rate | 2.84 L/M |
| Data Storage | 1000 or 10000 |
| Sensor Life | 2-3 Years |
| Operating Time | 6 – 8 hours |
| Environmental | -- |
| Temperature | Temperature |
| Humidity | < 85%RH |
| Atmosphere Pressure | 86- 106Kpa |
| Housing | High Impact Plastic |
| Dimension in mm | 115 (W) X 180 (H) X 60(D) |
| Weight | 0.6 KG |
| Warranty | One Year |
| Product Code | NO. ATS-101M |
Preferred Buyer From
| Location | Anywhere in India |
Portable Single Gas Detectors
Model ATS-101M is Portable Single Gas Detectors are capable of detecting Oxygen, Toxic, and Combustible gases making them ideal for use in various environments.
Portable Multi Gas Detector
Model ATS-103M is Portable Multi Gas Detector are capable up to Five Gases in One Instruments and detects all Toxic, Explosive and VOC (Volatile organic Compound) Vapour make them ideal use in variety of applications
- Suitable for all Toxic Explosive & Oxygen Gases
- Microcontroller based embedded intelligent instruments
- 128 x 64 Graphics LCD Display
- Diffusion or Auto Suction Sampling Mode
- Long Life Rechargeable Li-Ione Battery
- Data Logger with RS 232 and USB Computer Interface
- On Site Printing
Applications :
- Personal Monitoring
- Confined space entry
- Pulp & Paper
- Chemical Plants
- Refineries/Petrochemical
- Hazardous Area
- Water/West water Treatment
- Fire Services Mines
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Type | EC |
| Application | Leak Detection |
| Color | Grey, blue |
| Feature | Accuracy, Alarm System, Durable, Easy To Use, Rechargeable |
| Condition | New |
| Warranty | 1Year, One Year |
| Gas Type | Combustible Gas, Natural Gas |
| Country of Origin | India |
| Weight (g) | 350gm |
| Battery Type | Rechargeable Lithium Battery |
| Response Time (s) | 30 seconds at 95% variation |
| Sensor Life | 2-3 Years |
| Brand Name | Applied Techno Systems |
| Storage Temp | 20 deg C to 45 deg C |
| Working Temp | -5 deg C to 55 deg C |
| Power supply | Internal Ni-cad Battary |
| Product Code | 103M |
| Payment Terms | T/T |
| Delivery Time | 1 Week |
| Packaging Details | normal packing |
Preferred Buyer From
| Location | Anywhere in India |
PORTABLE SINGLE/MULTI GAS MONITOR ( MODEL ATS-103M )
Portable and multi-gas detector simultaneously monitors and displays up to
five gases. The compact and field tough ATS-103M features a non-intrusive
integrated sampling pump designed for performance, reliability and ease-ofuse.
It's optional Data Logging and computer interface features can be used for
further detailed analysis.
DSEPSECCRIIAPLT IOFNEATURES
Diffusion or Suction Sampling
Long Life Rechargeable Batteries
Data Logging and Rs 232 Output Capability
Operation modes: Real time always ready
Light weight, handy and simple to use
Sampling probe
CSIR-CIMFR Approved
Automatic Operation
Self Diagnostic Check
Proven Sensor Technology
Continuous, Stable Alphanumeric
Display
Customized Visual & Sound Alarms
Suitable for use in hazardous area
Class-1, Div.-1, Groups A, B, C & D
Zone ‘0’ of Gas Group IIC
On Start Up, The Instrument Automatically Goes Through Complete Self Integrity Check,
On Demand. The Press Of Sampling Switch Initiates The Sampling Through Suction
Analysis And Digitally Displays The Results. “Hold Key” Enables Monitor/Analysis for
a ParticularParameter of Interest.
DE SOCRPIPTTIIOONNS
CSIR-CIMFR
Approved
Model ATS-103M
Applied Techno Engineers Pvt. Ltd.
An ISO 9001:2015 Company
Process Monitoring Instruments
Display : 128 x 64 LCD Graphics Display with backlit
Sampling : Diffusion or Suction through inbuilt pump( with capacity of 30 mtr)
Calibration : Automatic zero & span with fresh air sample Calibration gases
Response Time : <10 seconds at 95% variant
Power Supply : Internal Lithium Rechargeable battery with 230V AC 50Hz charger
Working Temperature : -5°C to 55°C
Storage Temperature : -10°C to 55°C
Case : High Impact Plastic (NEMA IP 65) [IP 68 Optional]
External Dimension : 170 X 100 X 130 mm
Weight : Multi Gas 400 gm (with battery) & Single Gas 250gm (with battery)
Sampling Probe & Hose: 6mm, Dia SS 316 mm length with 10 meter Neoprene Hose
standard Accessories : 250VAC 50Hz Battery charger, Carrying Case
Relative Humidity : 0-95% RH (non condensing)
| Business Type | Manufacturer, Supplier, Retailer, Wholesaler |
| Measurement Range: | 0-25% & 0-100% V/V |
| Battery Type | Rechargeable Lithium Battery |
| Battery Life (hr.) | 6 to 8 hr |
| Sensor Type | EC |
| Sensor Life | 2-3 Years |
| Accuracy (%) | +/-2%. |
| Brand name | Applied Techno Systems |
| Display | 128 x 64 graphics LCD |
| Resolution | 0.1 or 1 PPM % as applicable |
| Accuracy | +/- 2% & 0.5 for Oxygen |
| Repeatability | +/-1% |
| Temp Range | 0-55 deg C |
| Battery Life | 6-8 hours |
| Housing | High Impact Plastic |
| Power Supply | 3.7 VDC Lithium Rechargeable Battary |
Preferred Buyer From
| Location | Anywhere in India |
Features :
- Complete Automatic Operation
- LCD Display
